OD Grinder SG CNC Machine Smart SG-220 CNC

Send Inquiry

Request To Call Back

OD Grinder SG CNC Machine Smart SG-220 CNC

Get a Price/Quote

MOQ : 1 Unit

OD Grinder SG CNC Machine Smart SG-220 CNC Specification

Rotation
Left & Right

Model
Smart SG-220 CNC

Product Type
OD Grinder Machine

General Use
Precision external (OD) cylindrical grinding

Material
Heavy-duty cast iron, high-grade steel

Type
Surface Grinder

Capacity
200 mm OD x 500 mm Length

Weight (kg)
Approx. 2200 kg

Computerized
Yes

Automatic
Yes

CNC Or Not
CNC

Control System
Siemens CNC Controller

Table Size
200 x 500 mm

Table Slide Way
Box type hardened & ground

Magnetic Chuck Size
200 x 500 mm

Grinding Wheel Size
400 x 50 x 203.2 mm

Grinding Wheel Speed
1450 RPM

Grinding Length
500 mm

Floor Space
2200 x 1600 x 1800 mm

Fuel Tank Capacity
60 L

Spindle Speed
Variable, upto 1450 RPM

Power
7.5 kW

Voltage
415 V, 3 Phase, 50 Hz

Dimension (L*W*H)
2200 x 1600 x 1800 mm

Feature
High precision grinding, user-friendly CNC system, automatic lubrication, coolant system

Color
White / Grey

Lubrication System
Fully automatic centralized

Tailstock Quill Travel
50 mm

Repeatability
2 micron

Workhead Motor
2 HP

Programming Interface
Touchscreen, G-code compatible

Min Grinding Diameter
10 mm

Safety Features
Overload protection, emergency stop

Swing Over Table
250 mm

Workhead Swivel Range
90 Degrees

Standard Accessories
3-jaw chuck, diamond dresser, coolant kit, splash guard

Coolant System
Fitted with pump, 120 L/min

Max Grinding Diameter
200 mm

OD Grinder SG CNC Machine Smart SG-220 CNC Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash Against Delivery (CAD), Cash in Advance (CID)

Supply Ability
10 Units Per Month

Delivery Time
5-7 Days

Main Domestic Market
All India

About OD Grinder SG CNC Machine Smart SG-220 CNC

Discover the eminent Smart SG-220 CNC OD Grinder, a monument to advanced engineering and precision. Popular among India's leading manufacturers and suppliers, this venerable machine boasts a maximum grinding diameter of 200 mm, Siemens CNC controller, and an intuitive touchscreen interface. With features like a robust coolant system, fully automatic lubrication, overload protection, and repeatability up to 2 micron, the Smart SG-220 ensures outstanding reliability. Reserve your SG-220 CNC today and try now for monumental productivity in precision OD grinding tasks.

Versatile Surface Applications and End Users

The Smart SG-220 CNC OD Grinder is ideal for precision external cylindrical grinding in the automotive, aerospace, toolmaking, and general engineering sectors. Designed for engineers and manufacturers who require superior surface finishing, this machine delivers high repeatability for a wide range of workpieces. Its user-friendly CNC system assures consistent results, making it a popular choice for both small-batch and continuous production environments demanding eminent accuracy.

International Exports, Secure Packaging, and Trusted Certifications

Shipped globally with robust packaging to ensure product safety, the Smart SG-220 CNC is exported to multiple countries at the lowest price. It adheres to international quality standards for safety and performance, making it the preferred choice for overseas buyers. Flexible payment terms and authoritative certifications accompany every shipment, guaranteeing a seamless purchase experience for any manufacturer seeking reliable and timely machine delivery.

FAQ's of OD Grinder SG CNC Machine Smart SG-220 CNC:

Q: How can the Smart SG-220 CNC machine improve my production process?

A: The Smart SG-220 CNC offers high precision, quick setup with its touchscreen interface, automatic lubrication, and effective coolant management. This results in consistent, high-quality grinding and reduced downtime in your workflow.

Q: What types of jobs is this OD Grinder most suitable for?

A: It excels in external cylindrical grinding of automotive parts, aerospace components, tools, and general engineering applications where high accuracy and impeccable surface finish are essential.

Q: Where is the Smart SG-220 CNC manufactured and supplied from?

A: The machine is manufactured and supplied by eminent producers in India, serving a global customer base with a reputation for reliability and technical support.

Q: What is the process for reserving and purchasing the Smart SG-220 CNC?

A: You may reserve the machine through direct order or inquiry with the manufacturer or supplier. Orders can be customized with payment terms and reliable export packaging for secure delivery.

Q: What safety features ensure the reliable usage of this grinder?

A: The machine is equipped with overload protection, emergency stop, splash guard, and a fully automatic lubrication system, ensuring both operator safety and machine longevity.
